Description | en
2.2 Trademarks
The above trademarks are only registered in certain countries and not necessarily
in the country where this document was published.
3 Description
3.1 Product overview
The scope of supply of the device may be expanded by accessories. The basic set
can be combined with sensors and hoses for remote measurement. This requires
the Dräger X-am pump to be connected using the Dräger X-act 7000 coupler.
3.1.1 Dräger X-act 7000
Graphic A
3.1.2 Basic set
Graphic B
Pay close attention to the instructions for use of additional parts, where available.
The following components are included in the scope of supply:
NOTICE Indicates a potentially hazardous situation
which, if not avoided, could result in dam-
age to the product or environment.
Alert icon Signal word Consequences in case of nonob-
servance
Trademark Trademark owner
X-act
®
Dräger
X-am
®
Dräger
Dräger-Tube
®
Dräger
No. Designation No. Designation
1 X-act 7000 7 Holder for Coupler
2 Device keys 8 Ring for carrying strap
3 Display 9 Battery cover
4 LED signal light 10 Retainer for Dräger MicroTubes
5 Infrared interface 11 Mini USB port
6 Gas inlet 12 Gas outlet
No. Designation Order number
Basic set: 8610800
1 X-act 7000
2 Dräger MicroTubes Demo 8610290
3 Torx screwdriver (T10) 8326823

Dräger X-act 7000 Specifications

General

Brand	Dräger
Model	X-act 7000
Category	Test Equipment
Language	English
