19
Once all interior packaging has been
removed from the laser, locate both zip
ties securing the Laser Head and Gantry.
One zip tie can be found at each end of
the Gantry.
Using a small pair of scissors or diagonal
cutting pliers, carefully cut and remove
both zip ties. DO NOT cut any other cord
or wire. Be aware that the Laser Tube is
extremely fragile. Be careful NOT to
damage any part of the machine during
this process.
Cut and Remove Zip Ties
Fig. 5
SETUP
Observe all provided warnings and safety instructions prior to and
when using the Dremel LC40 Laser Cutter. Failure to do so may
result in fire, equipment damage, property damage and/or personal injury, up to and
including death.
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive
safety measures reduce the risk of starting the laser cutter accidentally.
