Dremel DIGILAB LC40 Operating And Safety Instructions

20
Place the Honeycomb Plate inside the
laser on the laser bed. Be careful not to
damage any part of the Dremel LC40
Laser Cutter during this process. The
head can be moved out of the way by
hand if necessary.
The Honeycomb Plate sits flat at the
bottom of the Dremel LC40 Laser Cutter.
There is a slight recess in the bed to help
align the Honeycomb Plate (Fig. 6).
Install Honeycomb Plate
Fig. 6
SETUP
Remove the cap from the camera lens on
the Laser Head (Fig. 7).
Remove Camera Lens Cap
Lens
Cap
Fig. 7
Camera
Recess
in Laser
Bed
Recess in
Laser Bed
DM 1600A01CX8 08-18 LC40 EN.qxp_LC40 8/17/18 10:32 AM Page 20
