Dremel DIGILAB LC40 User Manual

14
Two person lift
required.
Lifting the
laser cutter alone may result in personal
injury.
Create a workstation. Prepare a flat,
sturdy table or workbench that can
support the weight of the Laser and Hex
Box™. The workstation should be close to
an electrical outlet and allow for
necessary ventilation described in the
SETUP section "Exhaust Connections"
page xx.
Open the top of the box.
1. Remove Reusable Tote Bag from
packaging and pull out box 1. Open lid
to reveal the project sample material
and the Honeycomb Plate.
2. Remove Instructional Manual, Water
Hoses, Air Tube, Screws, Hex Box™
Cap, Hex Key Wrench, Spacer Puck
from box 2.
3. Remove foam to reveal the Laser
Cutter. Use two people to lift Laser
Cutter out of box by straps and place
on workstation. After the Laser Cutter
has been taken out of the box, hook
straps to the Reusable Tote Bag. DO
NOT CUT STRAPS.
4. Open the lid of the Laser Cutter to
reveal box 3 with Hex Box™, Exhaust
Duct, and Exhaust Shroud.
Note: Save the Dremel DigiLab Laser
Cutter packaging for future transport and
storage.
UNPACKING
Box 2
Tote Bag
& Box 1
LC40
1 2
3 4
Box 3
Straps
