Menu Bar
HOME JOB HISTORY TOOLS NETWORK
HOME — Access to laser head position
controls and to test fire the laser.
JOB HISTORY — Lists previously run jobs
and provides option to re-run them.
TOOLS — Information about the unit and
settings.
NETWORK — Information and access to
network connection settings.
When necessary, the LCD touch screens will offer options to return to the previous screen
or advance to the next screen.
Tap to return to previous screen.
Tap to proceed to the next screen.
LCD TOUCH SCREEN
Status Icon Name What it means
Ethernet
LC40 is connected to a computer or a network router via
Ethernet Port.
The icon will disappear when there is no Ethernet connection.
Wireless
LC40 is connected to a computer or network router via wireless.
The icon will disappear either when there is no wireless
connection or when the Ethernet icon is active. When LC40 is
connected with both Ethernet and Wireless, only the Ethernet
icon will display.
Water
Cooling
WHITE: Cooling system functioning normally.
RED: Cooling system needs attention.
Vent
Fan
WHITE: Vent fan functioning normally.
RED: Vent fan needs attention.
Air
Assist
WHITE: Air assist functioning normally.
RED: Air assist needs attention.
Lid WHITE: Lid is closed. RED: Lid is open.
Status Bar
Note: Water Cooling. Vent Fan and Air Assist icons will only update in real time. (When the Hex Box
is activated by the LC40).
