DREMEL LC40 CONTROL SOFTWARE
This section introduces the major interface features of the Laser Control Software. The Laser
Control Software is a combination of print driver and control software that communicates
with, downloads jobs to, and controls the laser system. There is no download required. The
software will link a web browser with the LC40 using the IP address (found at the bottom of
the LCD home screen) on the local connection (Wireless or Ethernet).
Menu Bar — includes the following
menu options: File, Edit (shown when
a project is opened), and Help.
Tool Bar — includes the following
tools: Import, Undo, Redo, Auto
Array, Material, Time, Options, Run
Perimeter, and Start.
Workspace — On-screen area where a
job is created. Provides a graphical
representation of the intended job
and its position relative to the
general boundaries of the laser
working area.
Project Name — displays the name of
the current project.
Zoom In — enlarges workspace screen
detail.
Zoom Out — reduces workspace
screen detail.
Return to Default Size — auto size to
fit window.
Status — displays status of the
current project.
