Dremel DIGILAB LC40 User Manual

85
SHIPPING AND STORAGE
Two person lift
required. Lifting the
laser cutter alone may result in personal
injury.
Shipping the Laser Cutter
Refer to the unboxing section on page 14
of the manual for help in returning the
LC40 to its original packaging
configuration.
1. Unplug and wind up the power cord.
2. Unplug the hex box connector cord.
3. Disconnect the Ethernet cable.
4. Disconnect the air tube.
5. Disconnect the exhaust hose by
loosening the hose clamp.
6. Drain the cooling water. Place the hex
box in a suitable container to capture the
system water. Place the container in a
location below the LC40. Remove the cap
from the water tank. Disconnect the clear
inlet water hose from the hex box and
allow the water to drain. This will drain
the water from both the hex box and the
LC40 laser tube. It is important to drain
as much water as possible in case of
freezing weather. Tilting the hex box
back and forth will help drain the water.
7. If shipping the LC40 in its original carton.
Remove the 4 scr ews securing the
exhaust shroud and place the exhaust
shroud in its carton.
8. Remove the honeycomb plate and place
it in its package.
9. When placing the LC40 in its original
carton try to replace the foam pads in
the order they came out. It is important
the foam pads securely capture the
gantry system. Secure the gantry with
plastic ties to minimize any movement of
the gantry during transportation.
10. Return the hex box to its original
shipping location inside the laser
enclosure. If it cannot be placed inside,
it must be secured to the pallet outside
of the laser.
11. When shipping the LC40 the unit must
be secured to a pallet to prevent
damage
Storing the Laser Cutter
1. Unplug and wind up the power cord.
2. Unplug the hex box connector cord.
3. Disconnect the Ethernet cable.
4. Disconnect the air tube.
5. Disconnect the exhaust hose by
loosening the hose clamp.
6. Drain the cooling water. Place the hex
box in a suitable container to capture the
system water. Place the container in a
location below the LC40. Remove the cap
from the water tank. Disconnect the clear
inlet water hose from the hex box and
allow the water to drain. This will drain
the water from both the hex box and the
LC40 laser tube. It is important to drain
as much water as possible in case of
freezing weather. Tilting the hex box
back and forth will help drain the water.
7. Store in a clean, dry dust free
environment within a temperature range
of 60-85 F (16-29C). Keep the laser
covered to minimize dust build up inside
the laser enclosure.
Fig. 31
Observe all provided warnings and safety instructions when using
the Dremel LC40. Failure to do so may result in fire, equipment
damage, property damage or personal injury.
