Ducati 999S User Manual

41
E
Front fork adjusters
The front fork has rebound, compression damping
adjusters and spring preload adjuster.
This adjustment is done using the outer adjusters:
1) to adjust rebound damping (fig. 35);
2) to adjust inner springs preload (fig. 35);
3) to adjust compression damping (fig. 36.1 - 36.2).
Put and secure the motorcycle on side stand.
Turn the adjuster (1) on fork leg top with a flat
screwdriver to adjust rebound damping.
To reach the adjuster (3, fig. 36.1 - 36.2), insert a
screwdriver into the passing hole on the wheel shaft at
fork leg axis.
As you turn the adjusting screws (1 and 3), you will hear
them click. Each click identifies a setting.Turn the screw
all the way in to set the hardest damping (position 0).
This will be your starting point. Now turn the screw
anticlockwise and listen for the clicks that identify setting
positions no. “1”, “2” and so on.
A
2
1
fig. 35

Ducati 999S Specifications

General

Displacement	998 cc
Transmission	6-speed
Rear Brakes	Single 240 mm disc, 2-piston caliper
Bore x Stroke	100 mm x 63.5 mm
Frame	Tubular steel trellis
Engine Type	L-twin, 4 valves per cylinder, Desmodromic
Front Suspension	Showa 43 mm fully adjustable upside-down fork
Rear Suspension	Fully adjustable Ohlins monoshock
Front Brakes	2 x 320 mm discs, 4-piston calipers
Fuel Capacity	15.5 liters
Fuel Injection	Marelli electronic fuel injection
Exhaust	2-1-2 system with catalytic converter
Torque	106 Nm @ 8, 000 rpm
