50
T
ruing up Printed Pages
A
vailable only when sorter is installed
Adjust when the edges of the printed pages are not trued up.
■
Adjusting jump plate
Adjust the plate according to the paper size.
Ex:
Expand the guides fully when using paper with B4
or lar
ger size.
■
T
ruing up printed pages
When using thinner paper
, turn the lev
er up.
When using thicker paper
, turn the lev
er down.
Print Output
51
53
