EN
12 2016/11SE
9
10
11
• Now place the collector vessel vertically
downwards into the retaining clip mouldings
on the basic unit�
• Hang the handpiece holder (24) into position
on the basic unit�
• Place the suction handpiece into the hand-
piece holder�
When ready to use the appliance, insert the
suction cannula into the cannula retainer piece
on the suction handpiece� This cannula retainer
is designed for cannulae up to 6 mm in
diameter�
10. Operating the appliance
Before treating a patient, we strongly recom-
mend that two capfuls (approx� 40 ml) of Orotol
Plus (or any other agent specifically approved by
Dürr Dental) be poured into the collector vessel�
10.1 Switch the appliance On/Off.
Appliance switch has LEDs (25)
• To switch on the appliance, press switch sym-
bol "I"�
• To switch off, press the symbol "0"
Model 0670-02
When using the foot switch, the
appliance switch should be in the OFF
position
24
25
26
