4.3 Battery Pack 4 Replacement Procedures
Satellite C40-G/Pro-C40-G Maintenance Manual 4-10
NOTE: Dispose of the used battery packs as required by local ordinances or
regulations.
Installing Battery Pack
Install battery pack according to the following procedures and Figure 4-9.
CAUTION: The battery packs contain a lithium ion battery, which can explode due to
improper replacement, use, handling, or disposal. Always dispose of the battery packs as
required by local ordinances or regulations. Use only replacement batteries
recommended by Toshiba.
NOTE: Visually check the battery's terminals. If they are dirty, clean them with a dry
cloth.
1. Take a new or recharged Battery Pack.
2. Place Battery Pack in correct position.
3. Secure Battery with four M2.0x3.0x4.5 black Phillips head screws.
4. Check the battery screw hole ,if there is cracking,please replace the parts.
5. Connect Battery cable to CN3 on system board.
6. Installing Battery Maly.
