4.4 SSD 4 Replacement Procedures
Satellite C40-G/Pro-C40-G Maintenance Manual 4-12
Installing SSD
Install SSD according to the following procedures and Figures 4-13.
1.Insert SSD into CN8 on system board.
2.Secure it with one M2.0x2.5x5.0 black Phillips head screw.
3.Install thermal silica gel
CAUTION: Do not touch the connectors on SSD and in the computer with your bare
hands. SSD can fail if they are contaminated with sweat, natural oils, etc. from your hand
To Next Page
