Eaton 9155 N User Manual

26 8-10 kVA, 50/60 Hz (1-phase input) &
8-15 kVA, 50/60 Hz (3-phase input)
P-164000341
User's Guide Revision 1
9155 (3P
in/1P
out)
Input
Fusing (FUSE A)
with different input voltages
Cabling (CABLE 1)
with different input voltages
UPS
rating
(kVA)
230 V 400 V 440 V 480 V 690 V 230 V 400 V 440 V 480 V 690 V
8 kVA 50 A 25 A 25 A 20 A 20 A 10
mm²
6 mm² 6 mm² 6 mm² 6 mm²
10 kVA 50 A 25 A 25 A 25 A 20 A 10
mm²
6 mm² 6 mm² 6 mm² 6 mm²
12 kVA 63 A 40 A 40 A 25 A 25 A 16
mm²
10
mm²
10
mm²
6 mm² 6 mm²
15 kVA 80 A 50 A 50 A 32 A 32 A 16
mm²
10
mm²
10
mm²
6 mm² 6 mm²
9155 (3P
in/1P
out)
PE Output Battery
UPS
rating
(kVA)
Cabling
(CABLE 2)
Nominal
current
Cabling
(CABLE 2)
Fusing
(FUSE C)
Cabling
(CABLE 3)
8 kVA 10 mm² 38.8 A 10 mm² 50 A 10 mm²
10 kVA 10 mm² 43.5 A 10 mm² 50 A 10 mm²
12 kVA 16 mm² 52.2 A 16 mm² 50 A 10 mm²
15 kVA 16 mm² 65.2 A 16 mm² 50 A 10 mm²
Table 6-2: Recommended cable and fuse sizes for 9155 NT-model

Eaton 9155 N Specifications

General

Brand	Eaton
Model	9155 N
Category	UPS
Language	English
