Description Available settings Default setting
XSlot input signal (long break via
Rx)
Nothing
XSlot shutdown signal activation
delay before the signal is accept-
ed.
Step: 1 sec. 5 sec.
Bypass and synchronisation:
Usage of bypass [Enabled], [Disabled] Enabled
Require synch at transfer on by-
pass
[Required], [Not Required] Not required
Transfer on bypass on overload [Immediately], [after delay] Immediately
Synchronization enable [Enabled], [Disabled] Enabled
Bypass voltage deviation high limit +1% ... +20%, step: 1% +10%
Bypass voltage deviation low limit -1% ... -20%, step: 1% -15%
Synchronization window 0.5 ... 3.0 Hz, step: 0.1 Hz ±2.0 Hz
Frequency slew rate (not in paral-
lel mode)
0.1 ... 3.0 Hz/s, step 0.1 Hz/s 0.2 Hz/s
Battery information and settings:
ABM charging cycling disable [Enabled], [Disabled] Enabled
Charging temp compensation [Enabled], [Disabled] Enabled
Battery size setting Step: 1 Watts/cell 24 Watts/cell
Number of 36 pcs. battery strings 0 (no batteries), 1, 2, 3, 4... 1 string
Battery low alarm level Step: 0.01 V/cell 1.88 V/cell
Automatic battery support test [Enabled], [Disabled] Enabled
Maximum charging current Step: 0.1 A [max. 25 Amps] 3 A
Output on, automatic delay time
before turning the output on
[Disabled], [Set delay, step: 1 sec] 0 sec.
Output off, automatic delay time
on battery after which output is
turned off
[Disabled], [Set delay, step: 1 sec] Disabled
User preferences:
