Eaton 9PX 1000i User Manual

Table 4. Electrical Input
Nominal frequency
50/60Hz, automatic
Frequency Range
40-70Hz before switching to Battery mode
Bypass Voltage Range
-20%/+15% nominal value (default)
Model
Default input
(voltage/current)
Nominal input voltage
Input voltage range
9PX1000IRT2U
230V/10A
200V, 208V, 220V, 230V,
240V
Load = 100%: 176-276V
Load < 33%: 100-276V
9PX1500IRT2U
230V/10A
9PX1500IRTM
9PX2200IRT2U
230V/12A
9PX2200IRT3U
9PX3000IRT2U
230V/16A
9PX3000IRT3U
9PX3000ITRM
Table 5. Electrical Input Connection
Model
Input connection
Input power cord
9PX1000IRT2U
IEC-C14
IEC 10A
9PX1500IRT2U
9PX1500IRTM
9PX2200IRT2U
IEC-C20
IEC 16A
9PX2200IRT3U
9PX3000IRT2U
9PX3000IRT3U
9PX3000IRTM
Table 6. Electrical Output
Model
Online mode
Battery mode
Voltage regulation
factor
±1%
±2%
Efficiency
98% (HE mode)
3K: 94%, 2.2K: 93%
3K: 89%
2.2K: 90%
Frequency
regulation factor
Phase-lock with the mains supply within
±5% of the nominal line frequency (±0.5%
of automatically selected nominal
frequency if this range is exceeded)
±0.5% of automatically selected nominal
frequency
Nominal output
200/208/220/230/240V (voltage settable)
Frequency
50 or 60Hz, automatic, or can be set to a fixed frequency output
The output is
overload
Online mode:
102%~130% : 12s
130%~150% : 2s
>150% : turned off in 300ms
Percentages are based on the nominal power values.
Switch can be set (please refer to Output Mode Settings on Page 14.
Battery mode:
102%~130% : 12s
>130% : 2s
>150% : turned off in 300ms
Stop output upon an overload alarm

Eaton 9PX 1000i Specifications

General

Power Rating	1000 VA / 900 W
Output Voltage	230V
Input Voltage	230V
Output Power Factor	0.9
Nominal Voltage	230V
Frequency	50/60 Hz
Typical Recharge Time	3 hours
Operating Temperature	0-40°C
Operating Humidity	0-95% non-condensing
Battery Type	Sealed Lead Acid
Interface	USB
Input Voltage Range	176-276 V
User-selectable Output Voltage	200, 208, 220, 230, 240 V
Safety Approvals	CE, CB
Form Factor	Rack/Tower Convertible
Efficiency	Up to 98%
