User Manual MN04200002E
Effective January 2016
C441 Ethernet module user manual
(C441R, C441T, C441U, C441V)
EATON www.eaton.com
5 Conguration
5.1 Configuration Using a Web Browser
The Ethernet module includes an embedded web page that provides
the ability to monitor the status and set the configuration of the
Motor Insight device and the Ethernet module.
The web pages have been validated for use with Internet Explorer.
To use the web page open your Internet Explorer browser and enter
the IP address assigned to the Ethernet module:
http:// IP Address
The web page provides five levels of authorization as shown in the
chart below:
Level
Default
User Name
Default
Password Description
Open <none> <none> Open access, has no password. Allows
opening web page to be viewed, but no
additional information is available
Read_Only readonly readonly Read_Only access allows parameters to be
viewed, but no control or configuration
Control control control Control provides capabilities of Read_Only
plus allows motor and discrete outputs to
be turned on and off
Config configuration configuration Config provides capabilities of Control plus
the ability to set configuration values.
Super_
User
superuser superuser Super_User provides the capabilities of
Config plus the ability to change user
names and passwords.
In addition to the individual levels, a password exemption setting is provided. This
setting specifies a level that can be accessed without any password protection. The
default value of the password exemption is Super_User. All capabilities of the
web page are accessible without a password prompt until the password exemption is
changed to a lower level.
User names and passwords are case sensitive, and limited between 6~16 characters.
For security reasons, it is recommended that the user change the default passwords
and adjust the password exemption level to be lower than Super_User after configura-
tion. It is also recommended that these changes be made within a local subnet.
5.2 Configuration Using an EDS File
Multiple EDS files are available for the Ethernet Module depending
on the configuration of the module:
•
Connected to the C441 Motor Insight
•
Connect to the C440 overload relay
•
Connected to the S611 Soft Starter
•
Connected to the S811+ Soft Starter
•
Stand Alone I/O
These EDS file can be imported into any EtherNet/IP configuration
tools that support EDS files.
The EDS files can be downloaded from the Eaton web site:
http://www.eaton.com/electrical
6 EtherNet/IP Protocol Support
6.1 Supported Connections
The Ethernet Module allows the Connected device to connect on
EtherNet/IP. It can be connected both as an Explicit Message server
and as an Implicit (I/O) message target.
The Implicit connections supported include:
•
Exclusive Owner
•
Listen Only
•
Input Only
6.2 EtherNet/IP Object Model for C441 Motor Insight
Full Profile for Motor Insight
The table below shows the supported classes of the Ethernet
Module when connected to a Motor Insight overload and monitoring
relay.
Class Object
# of
Instances Description
0x01
(hex)
Identity 1 Provides module identity object:
See details below.
0x02 Message
Router
1 Internal object implemented per ODVA specifica-
tion.
0x04 Assembly
Object
(See
assembly
object
details)
Binds attributes from multiple objects for access
with a single Implicit (I/O) connection.
See details below.
0x06 Connection
Manager
1 Internal object supporting connection manage-
ment. Implemented per ODVA specification.
0x08 Discrete
Input Point
4 Status information for the discrete Inputs.
See details below.
0x09 Discrete
Output
Point
2 Status and control for the discrete Outputs.
See details below.
0x29 Control
Supervisor
1 Motor control functions. See details below.
0x2C Overload 1 Motor overload protection. See details below.
0x93 Voltage
Monitor
1 Vendor Specific object for monitoring motor volt-
age. See details below.
0xF5 TCP/IP
Interface
1 Information about the TCP/IP Interface.
Implemented per ODVA specification.
0xF6 Ethernet
Link
2 Ethernet link object for each of the 2 Ethernet
ports on the device. Implemented per ODVA
specification.
Object Details
Identity Object
Class: 1 (0x01)
Table 15. Instance Services
Service
Code
Service
Name
Service
Data Description
0x05 Reset 0 Instance 1: Initializes adapter to the Power-up state.
0x05 Reset 1 Instance 1: Writes default values to all instance
attributes AND then saves all non-volatile attributes
to FLASH memory AND then performs the equivalent
of a Reset(0).
0x05 Reset 101 Vendor specific reset — perform Intercom divorce.
0x0E Get_
Attribute_
Single
n/a Returns the value of the specified attribute.
0x10 Set_
Attribute_
Single
value Sets the “value” into the specified attribute.
