User Manual MN04200002E
Effective January 2016
C441 Ethernet module user manual
(C441R, C441T, C441U, C441V)
EATON www.eaton.com
1 Introduction
The C441 Ethernet module enables Ethernet communications for
the following Eaton Devices:
•
C441 Motor Insight
®
overload and monitoring relay
•
C440 Overload and monitoring relay
•
S611 Soft Starter
•
S811+ Soft Starter
The device can also be used stand alone as an Ethernet I/O block.
The table below describes the products covered in this manual and
their primary usage
Table 1.
Product Selection
Catalog # Description Use With
C441R Plug In Ethernet Module with 120 Vac Inputs
and Relay Outputs
C441 Motor Insight
S611 Soft Starter
C441T Plug In Ethernet Module with 24 Vdc Inputs
and Relay Outputs
C441 Motor Insight
S611 Soft Starter
C441U Stand alone Ethernet Module with 120 Vac
Inputs and Relay Outputs
C440 Overload
As I/O Block
S811+ Soft Starter
C441V Stand alone Ethernet Module with 24 Vdc
Inputs and Relay Outputs
C440 Overload
As I/O Block
S811+ Soft Starter
The Ethernet module provides the following key features:
•
Supports EtherNet/IP protocol
•
Supports Modbus TCP protocol
•
Integrated web page for device monitoring and set up
•
Dual Ethernet ports with integrated switch
•
4 Discrete Input Points and 2 Output relays
•
Additional Modbus Serial monitoring port available for most con-
figurations
The Ethernet Module can simultaneously support data access from
EtherNet/IP originators and Modbus TCP clients.
2 Ratings
The following ratings apply to the C441R, C441T, C441U and C441V
Table 2. Ethernet Physical Layer Ratings
Description Rating
Media Wire
Ethernet Link Speed 10/100 MB
Auto MDIX support yes
# of Ports 2
Table 3. Environmental Ratings of the Module
Description Rating
Transportation and
Storage
Temperature -40°C – 85°C
Humidity 5 – 95% non condensing
Operating Temperature -20°C – 50°C (-40°F – 131°F)
Humidity 5 – 95% non condensing
Altitude Above 2000 meters (6600 feet), con-
sult factory
Shock
IEC 60068-2-27
15G any direction for 11 milliseconds
Vibration
IEC 60068-206
5 – 150 Hz, 5G, 0.7 mm maximum
peak-to-peak
Pollution Degree 3
Table 4. Approvals and Certifications
Electrical/EMC Rating
ESD Immunity (IEC61000-4-2) +/- 8 kV Air, +/-4 kV contact
Radiated Immunity (IEC61000-4-3) 10 V/m 80 – 1000 MHz, 80% amplitude
modulation @ 1 kHz
Fast Transient (IEC61000-4-4) +/- 2 kV using direct method
Surge (IEC61000-4-5) +/- 2 kV line-to-ground
RF Conducted (IEC61000-4-6) 10 V, 0.15 – 80 MHz
Ingress Protection Code IP20
Radiated and Conducted Emissions EN55011 Class A
Agency Certifications UL
®
508
cUL
®
(CSA
®
C22.2 No. 14)
CE (Low Voltage Directive)
ODVA EtherNet/IP Certified
Table 5. Input Power Supply Requirements
Description Requirement
Voltage Range 18 – 30 Vdc
Current Draw (Maximum) 50 mA
ote:N Any UL Listed power supply with an isolated 24Vdc voltage output can
be used provided that a UL listed or recognized fuse rated no more then 4A
maximum is installed
m WARNING
ONLY APPLY 24VDC TO THE MOTOR INSIGHT COMMUNICATION
MODULE POWER SUPPLY CONNECTOR. USE OF ANY OTHER
VOLTAGE MAY RESULT IN PERSONAL INJURY, PROPERTY
DAMAGE AND DAMAGE TO THE MODULE.
