28
User Manual MN04200002E
Effective January 2016
C441 Ethernet module user manual
(C441R, C441T, C441U, C441V)
EATON www.eaton.com
Class 44 (0x2C): Overload Object
Instance Count: 1
Instance List: 1
Table 46. C440 Overload Object Instance Attributes
Attrib NV Access
Data
Type Name Description
6 V Get USINT Phase
Imbalance
Percent
Percent of Measured Phase
Imbalance (%)
7 V Get USINT Thermal
Memory
Percentage
Present Thermal Value. 100%
equates to a trip condition. (%)
100 V Get USINT Overload Class The Present FLA Class. Class
settings are device dependent.
105 V Get UINT Scaled FLA
Setting
The Present FLA Setting. The
potentiometer selects this value.
The value is scaled by the multi-
plier. (Amps)
140 V Get UINT Scaled 3Phase
Ave Current
Average of the 3 Scaled RMS
Currents (Amps)
141 V Get UINT Scaled Current
Phase A RMS
Scaled RMS Current Phase A
(Amps)
142 V Get UINT Scaled Current
Phase B RMS
Scaled RMS Current Phase B
(Amps)
143 V Get UINT Scaled Current
Phase C RMS
Scaled RMS Current Phase C
(Amps)
144 V Get UINT Scaled Ground
Current RMS
Scaled Ground Current. (Amps)
150 V Get UINT Scaled Max
FLA
This is the max FLA setting pos-
sible in this device. The value is
scaled by the multiplier. (Amps)
151 V Get UINT Scaled Min
FLA
This is the min FLA setting pos-
sible in this device. The value is
scaled by the multiplier. (Amps)
152 V Get UINT Current Scale
Value
This value indicates the multipli-
er applied to the current values.
For example: If the multiplier is
10 then all currents are read out
in deciamps. 1A => 10A. (Scale)
153 V Get UINT Current as
Percentage
of FLA
Current as a percentage of FLA.
Ie: If Current is 1Amp and the
FLA is 1AMP the percent would
be 100%. (%)
154 V Get USINT Ground Fault
Percent
Percent of Ground Fault mea-
sured. GF% = GFC / ((.5)*FLA)
(%)
6.4 EtherNet/IP Object Model for Soft Starter
When the Ethernet module is connected to an S611 soft starter, the
presented object model is compliant with the ODVA Softstart Device
profile (type: 0x17).
Full Profile for S611
The table below shows the supported classes of the Ethernet
Module when connected to an S611 soft starter.
Class Object
# of
Instances Description
0x01
(hex)
Identity 1 Provides module identity object: See details in
previous section.
0x02 Message
Router
1 Internal object implemented per ODVA specifica-
tion.
0x04 Assembly
Object
6 Binds attributes from multiple objects for access
with a single Implicit (I/O) connection. See
details below.
0x06 Connection
Manager
1 Internal object supporting connection manage-
ment. Implemented per ODVA specification.
0x08 Discrete Input
Point
4 Status information for the discrete Inputs. See
details in previous section.
0x09 Discrete
Output Point
2 Status and control for the discrete Outputs. See
details In previous section.
0x29 Control
Supervisor
1 Motor control functions. See details in previous
section.
0x2C Overload 1 Motor overload protection. See details below.
0x2D SoftStart 1 Soft start object see details below.
0x93 Voltage
Monitor
1 Vendor Specific object for monitoring motor volt-
age. See details below.
0xF5 TCP/IP
Interface
1 Information about the TCP/IP Interface.
Implemented per ODVA specification.
0xF6 Ethernet Link 2 Ethernet link object for each of the 2 Ethernet
ports on the device. Implemented per ODVA
specification.
Object Details
Class 1 (0x01): Identity Object
Instance Count: 1
Instance List: 1
Table 47. S611 Identity Object Instance Attributes
Attrib NV Access
Data
Type Name Description
1 V Get UINT CIP
Vendor
ID
ODVA Assigned Vendor
Identification Number.
2 V Get UINT CIP
Device
Type
CIP Defined General Product Type.
3 V Get UINT Product
Code
Vendor Product Code
4 V Get UINT Firmware
Rev
Com Adapter Firmware Rev.
