Technical Specifications
Panel Specification
EFCV2ZONE EFCV4ZONE EFCV8ZONE
Power Specification
Input Voltage Range
18.75-30.7V DC
Maximum current drawn from battery 2.7A
Zone Circuits
Number of Zones 2 4 8
Devices per Zone Standard Conventional Mode: Max 32 Detectors and Manual Call Points
Intrinsically Safe Mode: Max of 10 Intrinsically Safe Detectors and Manual Call Points
Maximum loading per Zone 200mA
Standby Zone Voltage Vmin 19V DC
Vmax 23V DC
Alarm Zone Voltage Vmin 19V DC
Vmax 23V DC
Alarm Resistance
(Conventional Mode)
Rmin 100Ω
Rmax 750Ω
Fuse Protection Per Zone 250mA PTC
End of Line Termination Standard Conventional Zones: EOLM-1 only
Intrinsically Safe Zones: 6K8 resistor
WARNING: YOU MUST USE THE CORRECT END OF LINE TERMINATION
Conventional Sounder Outputs
Number of sounder outputs 2 2 4
Maximum loading per output 250mA
Fuse protection per output 250mA PTC
End of Line Termination per output 6K8 resistor
Unmonitored Outputs
Fire Relay Type Volt-Free, Single Pole Double Throw
Rating 30V DC, 1A
Fuse 500 mA PTC
Fault Relay Type Volt-Free, Single Pole Double Throw
Rating 30V DC 1A
Fuse 500mA PTC
Interlink Relay Type Volt-Free, Single Pole Double Throw
Rating 30V DC, 1A
Fuse 500mA PTC
Auxiliary Output V
18.15V - 30.7V DC
Imax 50 mA
Fuse 50mA PTC
Intrinsically Safe Barrier A MTL5561 (Dual Channel, can take 2 zones per barrier)
B MTL7778AC (Single Channel)
Unmonitored Inputs
Class Change Type Open Circuit: Normal Panel Operation
Short Circuit: Activate all Sounders
Communication Ports
Repeater Port Type RS485
Nodes 3
Note: The use of this port is outside the scope of EN54 certification
Environmental
Operating Temperature
°C -5°C to +40°C
Relative Humidity % 93% +/3% non-condensing
IP Rating IP30
Mechanical
Dimensions mm 375 (W) x 366 (H) x 134 (D)
Weight Kg
2.25
Material PC ABS Front and Rear
Technical Data 25-16733-A
Effective
October 2019
