Eaton EFCV2Z User Manual

28
Technical Data 25-16733-A
Effective October 2019
Installation and operation manual for
conventional fire panels
EATON www.eaton.com
Panel Specification (continued)
EFCV2ZONE EFCV4ZONE EFCV8ZONE
Cabling
Cable Access 29 x 20mm drill positions - Slots for rear cable entry
Cable Type Firetuf FT120 / FP200
Cable type 2 core 1.5mm, 2 screened fire rated cable
500m (max per zone)
Compliance
Compliance to Standards EN54 Part 2 CIE and Part 4 PSE, BS5839, part1
PSE Specification
EFCV2ZONE EFCV4ZONE EFCV8ZONE
Power Specification
Mains Voltage 230V AC -10% / +15%, 50Hz
Mains Fuse 1 Amp Anti-Surge
Battery Details
Number of Batteries 2
Capacity 12V, 5Ah
Recommended Battery Yucell Y5-12 (Yuasa NPH5-12)
Battery Fuse
6.3A Anti-Surge
Battery voltage (Charging value) 27.3V DC @20%
Recommended period for battery
replacement
5 years
* Batteries are not shipped with the EFCVXZONE-NB variants (NB: No batteries)
PSE Ratings
Output voltage
18.75-30.7V DC
Maximum ripple voltage 425mV rms (1.2Vp-p)
Imin 39mA
Imax.A 2.1A
Imax.B 2.6A
Ri max 1Ω
PSE Fault Options
Mains OK (J4 pin 4) >=3V Mains present, <=3V Mains fault
Fault_Charger (J4 pin 1)
>=3V for 1s pulsed at 0.2Hz Charger OK
>=3V for 1s pulsed at 1Hz Charger fault
Steady high/low (no pulsing) PSE Micro fault
Fault_Battery (J4 pin 3)
=0.17* (Vbat-0.6) Volts
0V (J4 pins 2 and 10) reference
EOLM-1 Specification
EFCV2ZONE EFCV4ZONE EFCV8ZONE
Power Specification
Operating Voltage
18.75-30.7V DC
Nominal Current 1.4mA
