M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 159
Maximum Cross-Sections
Notes

AWG = American Wire Gauge.

UL fuse with AWG.
L1, L2/N, L3 U, V, W PE R+, R—
mm
2
AWG

mm
2
AWG

mm
2
AWG

mm
2
AWG

MMX11AA1D7…
MMX11AA2D4…
MMX11AA2D8…
MMX11AA3D7…
2 x 2.5 2 x 14 3 x 2.5 3 x 14 2.5 14 — —
MMX11AA4D8… 2 x 6 2 x 10 3 x 6 3 x 10 ————
MMX12AA1D7…
MMX12AA2D4…
MMX12AA2D8…
MMX12AA3D7…
2 x 1.5 2 x 16 3 x 1.5 3 x 16 1.5 16 — —
MMX12AA4D8…
MMX12AA7D0…
2 x 2.5 2 x 14 3 x 2.5 3 x 14 2.5 14 — —
MMX12AA9D6… 2 x 6 2 x 10 3 x 6 3 x 10 6 10 — —
MMX32AA1D7…
MMX32AA2D4…
MMX32AA2D8…
MMX32AA3D7…
3 x 1.5 3 x 16 3 x 1.5 3 x 16 1.5 16 — —
MMX32AA4D8…
MMX32AA7D0…
3 x 1.5 3 x 16 3 x 1.5 3 x 16 1.5 16 — —
MMX32AA011… 3 x 2.5 3 x 14 3 x 2.5 3 x 14 2.5 14 2 x 2.5 2 x 14
MMX32AA012… 3 x 6 3 x 10 3 x 6 3 x 10 6 10 2 x 6 2 x 10
MMX32AA017…
MMX32AA025…
3 x 6 3 x 10 3 x 6 3 x 10 6 10 2 x 6 2 x 10
MMX32AA031…
MMX32AA038…
3 x 10 3 x 8 3 x 8 3 x 8 10 8 2 x 10 2 x 8
MMX34AA1D3…
MMX34AA1D9…
MMX34AA2D4…
MMX34AA3D3…
3 x 1.5 3 x 16 3 x 1.5 3 x 16 1.5 16 —
2 x 1.5
—
2 x 16
MMX34AA4D3…
MMX34AA5D6…
3 x 1.5 3 x 16 3 x 1.5 3 x 16 1.5 16 2 x 1.5 2 x 16
MMX34AA7D6…
MMX34AA9D0…
MMX34AA012
3 x 2.5 3 x 14 3 x 2.5 3 x 14 2.5 14 2 x 2.5 2 x 14
MMX34AA014… 3 x 4 3 x 12 3 x 12 3 x 12 4 12 3 x 4 2 x 12
MMX34AA016…
MMX34AA023…
3 x 6 3 x 10 3 x 6 3 x 10 6 10 2 x 6 2 x 10
MMX34AA031… 3 x 10 3 x 8 3 x 8 3 x 8 10 8 2 x 10 2 x 8
MMX34AA038… 3 x 10 3 x 6 3 x 8 3 x 6 10 6 2 x 10 2 x 6
MMX35AA1D7…
MMX35AA2D7…
3 x 1.5 3 x 16 3 x 1.5 3 x 16 1.5 16 2 x 1.5 2 x 16
MMX35AA3D9…
MMX35AA6D1…
MMX35AA9D0…
3 x 2.5 3 x 14 3 x 2.5 3 x 14 2.5 14 2 x 2.5 2 x 14
