Appendix A
160 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Specified Fuses and Disconnect Devices
Notes
Fuse UL-rated, Class J, 600V.
I
cn
10 kA.
Maximum permitted
line supply voltage
Part No. M-Max U
LN
[V] VDE [A] UL [A]
Type Designation Type Designation/Catalog No.
MMX11AA1D7… 1 AC 120V +10% 20 20 FAZ-B20/1N —
MMX11AA2D4… 1 AC 120V +10% 20 20 FAZ-B20/1N —
MMX11AA2D8… 1 AC 120V +10% 20 20 FAZ-B20/1N —
MMX11AA3D7… 1 AC 120V +10% 20 20 FAZ-B20/1N —
MMX11AA4D8… 1 AC 120V +10% 32 30 FAZ-B32/1N —
MMX12AA1D7… 1 AC 240V +10% 10 10 FAZ-B10/1N —
MMX12AA2D4… 1 AC 240V +10% 10 10 FAZ-B10/1N —
MMX12AA2D8… 1 AC 240V +10% 10 10 FAZ-B10/1N —
MMX12AA3D7… 1 AC 240V +10% 10 10 FAZ-B101/N —
MMX12AA4D8… 1 AC 240V +10% 20 20 FAZ-B20/1N —
MMX12AA7D0… 1 AC 240V +10% 20 20 FAZ-B20/1N —
MMX12AA9D6… 1 AC 240V +10% 32 30 FAZ-B32/1N —
MMX32AA1D7… 3 AC 240V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX32AA2D4… 3 AC 240V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX32AA2D8… 3 AC 240V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX32AA3D7… 3 AC 240V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX32AA4D8… 3 AC 240V +10% 10 10 FAZ-B10/3 PKM0-10/XTPM010BNL
MMX32AA7D0… 3 AC 240V +10% 10 10 FAZ-B10/3 PKM0-10/XTPM010BNL
MMX32AA011… 3 AC 240V +10% 20 20 FAZ-B20/3 PKM0-20/XTPM020BNL
MMX32AA012… 3 AC 240V +10% 20 20 FAZ-B20/3 PKM0-20/XTPM020BNL
MMX32AA017… 3 AC 240V +10% 25 25 FAZ-B25/3 PKM0-25/XTPM025BNL
MMX32AA025… 3 AC 240V +10% 32 40 FAZ-B32/3 PKM0-32/XTPM032BNL
MMX32AA031… 3 AC 240V +10% 40 40 FAZ-B40/3 PKM4-40/XTPM040BNL
MMX32AA038… 3 AC 240V +10% 50 50 FAZ-B50/3 PKM4-50/XTPM050BNL
MMX34AA1D3… 3 AC 480V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX34AA1D9… 3 AC 480V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX34AA2D4… 3 AC 480V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX34AA3D3… 3 AC 480V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX34AA4D3… 3 AC 480V +10% 10 10 FAZ-B10/3 PKM0-10/XTPM010BNL
MMX34AA5D6… 3 AC 480V +10% 10 10 FAZ-B10/3 PKM0-10/XTPM010BNL
MMX34AA7D6… 3 AC 480V +10% 20 20 FAZ-B20/3 PKM0-20/XTPM020BNL
MMX34AA9D0… 3 AC 480V +10% 20 20 FAZ-B20/3 PKM0-20/XTPM020BNL
MMX34AA012… 3 AC 480V +10% 20 20 FAZ-B20/3 PKM0-20/XTPM020BNL
MMX34AA014… 3 AC 480V +10% 25 25 FAZ-B25/3 PKM0-25/XTPM025BNL
MMX34AA016… 3 AC 480V +10% 25 25 FAZ-B25/3 PKM0-25/XTPM025BNL
MMX34AA023… 3 AC 480V +10% 32 40 FAZ-B32/3 PKM0-32/XTPM032BNL
MMX34AA031… 3 AC 480V +10% 40 40 FAZ-B40/3 PKM4-40/XTPM040BNL
MMX34AA038… 3 AC 480V +10% 50 50 FAZ-B50/3 PKM4-50/XTPM050BNL
MMX35AA1D7… 3 AC 575V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX35AA2D7… 3 AC 575V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX35AA3D9… 3 AC 575V +10% 6 6 FAZ-B6/3 PKM0-6.3/XTPM6P3BNL
MMX35AA6D1… 3 AC 575V +10% 10 10 FAZ-B10/3 PKM0-10/XTPM010BNL
MMX35AA9D0… 3 AC 575V +10% 20 20 FAZ-B20/3 PKM0-20/XTPM020BNL
