TRSM0940 Service Procedures | MHP/MXP/VHP/VXP Splitter Cylinder Disassembly and Assembly
MHP/MXP/VHP/VXP Splitter Cylinder Disassembly and Assembly
Special Instructions
During removal on 9-series UltraShift PLUS transmissions
the Auxiliary section requires R&R prior to Splitter Cylinder
removal. Damage to internal components will result if Auxil-
iary Section is not properly removed prior to Cylinder
removal.
During removal if replacing only the O-Rings in the Splitter
Cylinder, Auxil
iary Section removal is not necessary
During installation apply Eaton® Lubricant or equivalent to
Shift
Cylinder Assembly and insert valve O-Rings so a film
covers the entire surface of each O-Ring.
During installation apply Eaton® rust preventative #71213
or equivalent
to all Shift Cylinder walls and Yoke Bars, cover
the entire Yoke Bar surface that comes in contact with the
Shift Cylinder O-Ring.
Special Tools
• Typical Service Tools
• Vise with brass jaws or wood blocks
