TRSM0940 Service Procedures | MHP/MXP/VHP/VXP Auxiliary Section Assembly and Installation
MHP/MXP/VHP/VXP Auxiliary Section Assembly and Installation
Special Instructions
None
Special Tools
• Bearing Drivers
•Maul
• PVC Pipe
• RR1002TR Auxiliary Countershaft Support Straps
Component Identification
1. Sliding Clutch
2. Screw
3. Retainer
4. Splitter Gear
5. Tapered Roller Bearing
6. Bearing Sleeve
7. Snap Ring
8. Spring
9. Synchronizer Assembly
10. Sliding Clutch
11. Synchronizer Assembly
12. Mainshaft
13. Washer
14. Reduction Gear
15. Spacer
16. Tapered Roller Bearing
17. Output Yoke
18. Hex Flange Screw
19. Universal Joint Yoke
2
3
4
8
1
7
5
6
9
10
11
12
13
14
15
16
17
18
19
