Shift Bar Housing Disassembly and Assembly | Service Procedures TRSM0940
Shift Bar Housing Assembly
1. Place the Shift Bar Housing upside down on a work
bench.
2. Inst
all the bar in the first bore of the Shift Bar Housing.
3. Install the yoke loc
k screw and wire securely.
Note: Bra
ss covers must be used on vise teeth (if
used) to avoid damaging the Shift Bar Housing gasket
surface.
4. Install the actuating plunger
in the center boss bore.
5. In
stall one 3/4” interlock ball in the rear boss top bore.
This ball rides between the 1st-Reverse and 2nd-3rd
Gear Shift Bars.
Note: Coa
ting the 3/4” interlock balls with grease will
help keep them in place in the bores.
6. While holdin
g the notched end of the bar, install the
2nd-3rd Gear Shift Bar in the housing boss middle
bore. Position the shift block on the bar between the
center and rear bosses.
