3.2 Technical parameters
Table 3-2-1 Technical Parameters
category
name
parameter
power supply
Operating voltage
DC 8 to 28V
Operating current
50mA @12V
The power supply
indicates
Green LED indication
Serial
Communication
interface
RS485
baud rate
1200 to 115200 bps (default 9600 bps)
The data bit
8 (Fixed).
Check bit
No checks, parity, parity (default no checks)
Stop bit
1 (fixed).
Communication
protocol
Modbus RTU protocol
The device
address
1 to 247(default address 32:
Software
1, hardware 31).
DO output
The number of
DO roads
8 way
The DO output
type
Type C relay (normally open and normally closed)
DO output mode
Level mode, pulse mode
Relay contact
capacity
30V/10A☆250V/10A
The output
indicates
Red LED indication
other
Product size
145 mm x 90 mm x 40 mm (W.W.W. High)
Product weight
250g ± 5g
Working
temperature and
humidity
-40 to 85 degrees C, 5% to 95% RH (no condensation)
Store temperature
and humidity
-60 to 125 degrees C, 5% to 95% RH (no
condensation)
How to install it
Positioning hole installation, rail installation
