Ebyte 8DO User Manual

Chengdu Ebyte Electronic Technology Co.,Ltd. 【8DO】MA01 -XXCX0080 User Manual
Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd.
5
2.Quick start
If there is a problem during use, click on the official website link: https://www.ebyte.com/product-class.aspx
2.1 Use preparation
Serial I/O networked devices ("IO devices") are required to prepare computers, converters, power supplies,
screwdrivers and other related accessories before use. Here's how it works:
Table 2-1-1 Preparation List
serial
number
Devices
quantity
1
IO devices
1
2
USB re-serial converter
1
3
Configure the tool software
1
4
Computer
1
5
Power adapter(12V/1A).
1
6
Screwdriver (one word SL 2).
1
7
Signal generator (or sensor)
1
2.2 Equipment wiring
2.2.1 Power wiring
Power supply, powered by DC 8to28V, or DC 12V or 24V.
Figure 2-2-1 Power wiring diagram
