2010 dmm 25/96 599 73 68-54
5.1.1.6 Pushbuttons – LEDs and LCD
The functions of each button are defined by the configuration of the appliance.
• Button no. 1: ON/OFF
See description on page 11
Unlike the other versions, in the SERIES 9, after pressing the
ON/OFF button the LCD displays the time of day (for two seconds
to allow the user to check it and if necessary update it) followed
by the programme information.
• Sensor no. 1: TEMPERATURE
It is related to the part of the LCD display (see figure) where the
temperature of the washing cycle is shown.
The initial temperature displayed is that set for the chosen
programme.
Touch the sensor with your finger to lower it. Once you have
reached the lowest one, the selection starts off again from the
highest temperature.
The cold cycle is represented by the cold symbol and by two
dashes “ - - “ to replace the Digits.
The temperatures available (displayed in °C) are:
95°C, 60°C, 50°C, 40°C, 30°C, 20°C, cold cycle.
Concurrently with the display of the temperature in degrees, the
name of the selected function appears at the top of the display
in the text line.
• Sensor no. 2: SPIN SPEED
It is related to the part of the LCD display (see figure) where the
spin speed of the washing cycle is shown.
The initial speed shown on the LCD display is that configured for
the selected programme.
Touch the sensor with your finger to lower the speed. Once the
lowest speed has been reached, the next
selection is “Rinse Hold” and the related symbol lights up
(where compatible with the chosen programme), which is also lit
during the “Extra Silent” programme.
The next selection will be the speed configured for the
programme.
The spin speeds are:
1600–1400–1200–1000–800–600–400– “Rinse Hold” cycle.
When no speed is selected, or the “Rinse Hold” cycle is selected,
the LCD display shows three dashes
“
- - - ”.
Concurrently with the display of the spin speed in rpm, the name
of the selected function appears at the top of the display (in the
text line).
