Electrolux Washing machines User Manual

SOI/DT 2005-01 dmm 599 36 82-57
28/67
9.12 Wool programmes: cold – 30° - 40°
Motor Movement CYCLE
N.° PHASE Description Drain pump
Recirc.
Pump
Deterg.
Disp
Rpm Movem. Pause 40 30 *
1 Calibration Level ON OFF NO mov Drain
2 Water fill Level OFF OFF W NO mov SOFT_LEV
3 Maintenance & Refill Time OFF OFF W 35 1 40 1 min.
4 Water fill Level OFF OFF W NO mov WOOL_FIRST_W_LEV
5 Maintenance & Refill Time OFF ON (35/15) W 35 1 40
1 min.
WOOL_SEC_W_LEV
6 Heating Temperature OFF ON (35/15) W 35 1 40 38° 33° 20°
7 Maintenance Time OFF ON (35/15) W 35 1 40
T° ref
15 min.
T° ref
15 min.
T° ref
15 min.
8
WASH
Drain Time ON OFF NO mov Empty + 14 sec.
9 Water fill Level OFF OFF W NO mov WOOL_INT_R_LEV
10 Maintenance & Refill Time OFF ON (60/20) W 35 1 40
3 min.
WOOL_REF_R_LEV
11 Drain Time ON OFF NO mov Empty + 14 sec.
12
1st Rinse
Drain Time ON OFF 55 4 12 1 min.
13 Water fill Level OFF OFF W NO mov WOOL_INT_R_LEV
14 Maintenance & Refill Time OFF ON (60/20) W 35 1 40
3 min.
WOOL_REF_R_LEV
15 Drain Time ON OFF NO mov Empty + 14 sec.
16
2nd Rinse
Drain Time ON OFF 55 4 12 1 min.
17 Water fill Level OFF OFF SF NO mov WOOL_LAST_R_LEV
18 Maintenance Time OFF OFF 35 1 40 30 sec.
19 Water fill Level OFF OFF SF 35 1 40 Qsf (4 Litres)
20 Maintenance & Refill Time OFF ON (60/20) W 35 1 40
5 min.
WOOL_REF_R_LEV
21 Drain Time ON OFF NO mov Empty + 14 sec.
22
Rinses
Last rinse
(softener)
Spin Time ON OFF WF 1000 rpm
(The data are indicative)
SF = Softener W = Wash
