SOI/DT 2005-01 dmm 64/67 599 36 82-57
l) Place the control panel where it was before paying attention
that the wiring is positioned correctly.
m) Fasten all screws removed previously.
n) Set the knob.
15.2 Flow meter
If the flow meter malfunctions, the entire
solenoid valve assembly must be replaced.
15.3 Aqua Control
ª Disconnect the connector
ª Insert a screwdriver into the holes indicated by the arrows
and release the fasteners that attach the component to the
base frame.
ª To attach the cover onto the base frame:
ª First, slide in the part indicated by the arrow (A), then push
the cover in the direction shown by the arrow (B).
