SOI/DT 2005-01 dmm 599 36 82-57
55/67
12.3.1 Programme selector
In the table are indicated the closures between the contact C6 (common) and the other contacts (C1−C5) of
the programme selector in the different positions and the corresponding codification. The code is displayed
only in the appliances with display and LCD.
Selector position
Closure of selector contacts
(C6 is the common)
LCD
Type 16
Positions
(C1 is not featured)
C1 C2 C3 C4 C5
1 - Cancel
0 1 1 1 1
-------------
2
0 1 0 0 1
21
3
0 1 1 0 0
13
4
0 1 0 1 0
11
5
0 0 0 1 1
15
6
0 1 0 1 1
19
7
0 0 1 0 1
25
8
0 0 1 1 0
27
9
0 0 1 1 1
23
10
0 1 1 0 1
23
11
0 1 1 1 0
-------------
12
0 0 0 0 0
-------------
13
0 1 0 0 0
-------------
14
0 0 0 1 0
-------------
15
0 0 0 0 1
-------------
16
0 0 1 0 0
-------------
