SOI/DT 2005-01 dmm 5/67 599 36 82-57
1 Purpose of this manual
The purpose of this manual is to provide service engineers who are already familiar with the repair procedures
for traditional washing machines with information regarding appliances fitted with the EWM2000 EVO electronic
control system and produced in Porcia (Italy).
The electronic control system plus EWM2000EVO consists of a main electronic board and one
control/display board, “SIGMA LCD” version.
The following are described:
• General characteristics
• Control panel and washing programmes
• Technical characteristics
• Guide to the diagnostics
For detailed information concerning hydraulic circuit, structural characteristics of the appliances and
accessibility, please refer to Service Manual of washing machines and washer-dryers Series P6000/Nexus
(publication no. 599 35 23-17).
2 PRECAUTIONS
Electrical appliances must be serviced only by qualified Service Engineers.
Always remove the plug from the power socket before touching internal
components.
3 GENERAL SPECIFICATIONS
Programme selection
16 positions with incorporated main switch
Serial port
DAAS-EAP communications protocol up to 38400 baud
Voltage requirement
220/240V
50 Hz
Type of washing system
Jet-system
Type of rinsing system
Jet-system
Motor
Collector, with tachometric generator
Spin speed
900 ÷ 1600 rpm
Anti-unbalancing control
FUCS
Water fill control
Solenoid valves
Detergent dispenser
3 compartments: prewash/stain remover, washing, softener
4 compartments: prewash/stain remover, washing, softener,
bleach
Control of water level in tub
Two anti-boiling pressure switches
Anti-overflow pressure switch, Aqua control system
Analog pressure switch
Door interlocks
Traditional (with PTC)
Instantaneous (with or without microswitch)
Magnetic
Power of heating element
Up to 1950 W
Temperature control
NTC sensor
Audible signalling system
Traditional, included on display board
Sensors
Water level sensor
Turbidity sensor
