Emerson 3051SMV User Manual

Specifications and Reference Data
65
Specifications and Reference Data
January 2017
Reference Manual
00809-0100-4853, Rev AB
Temperature input
N
(8)
None ★
R
(9)
RTD input (type Pt 100, –328 to 1562 °F [–200 to 850 °C]) ★
Isolating diaphragm
2
(10)
316L SST ★
3
(10)
Alloy C-276 ★
5
(11)
Tant alum
7
(10)
Gold-plated 316L SST
Process connection
Size
Material type
Flange
material
Drain vent Bolting
000
None
(no process flange)
N/A N/A N/A N/A ★
A11
(12)
Assemble to Rosemount
305/306 Integral
Manifold
N/A N/A N/A N/A ★
A12
(12)
Assemble to Rosemount
304 or AMF manifold
with SST traditional
flange
N/A N/A N/A N/A ★
A15
(12)
Assemble to Rosemount
304 or AMF manifold to
SST traditional flange
with Alloy C-276 drain
vents
N/A N/A N/A N/A ★
A16
(12)
Assemble to 304 or AMF
manifold to DIN SST
traditional flange
N/A N/A N/A N/A ★
A22
Assemble AMF manifold
to SST coplanar flange
N/A N/A N/A N/A ★
B11
(12)(13)
Assemble to one
Rosemount 1199 Seal
N/A N/A N/A N/A ★
B12
(12)(13)
Assemble to two
Rosemount 1199 Seals
N/A N/A N/A N/A ★
C11
(12)
Assemble to Rosemount
405C or 405P Primary
Element
N/A N/A N/A N/A ★
D11
(12)
Assemble to Rosemount
1195 Integral Orifice and
Rosemount 305 Integral
Manifold
N/A N/A N/A N/A ★
EA2
(12)
Assemble to Rosemount
485 or 405A Annubar
Primary Element with
coplanar flange
N/A SST 316 SST N/A ★
Table A-6. Rosemount 3051SMV HART
®
and Fieldbus Ordering Information
The starred offerings (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject to
additional delivery lead time.
