Specifications and Reference Data
71
Specifications and Reference Data
January 2017
Reference Manual
00809-0100-4853, Rev AB
Transient protection
(33)
T1 Transient terminal block ★
Conduit electrical connector
(34)
GE M12, 4-pin, male connector (eurofast
®
) ★
GM A size mini, 4-pin, male connector (minifast
®
) ★
NACE
®
certificate
(35)
Q15 Certificate of compliance to NACE MR0175/ISO 15156 for wetted materials ★
Q25 Certificate of compliance to NACE MR0103 for wetted materials ★
Cold temperature
(19)
BRR –58 °F (–50 °C) cold temperature start-up ★
Typical model number: 3051SMV 3 M 1 2 G 4 R 2 E12 A 1A B4 C2 M5
1. For detailed specifications see “Specifications” on page 55.
2. For Measurement Types 1 and 2, only available with DP range codes 2, 3, and 4, 316L SST and Alloy C-276 isolating diaphragm and silicone fill fluid.
For Measurements Types 3 and 4, only available with DP range codes 2 and 3, 316L SST and Alloy C-276 isolating diaphragm and silicone fill fluid.
3. Only available with Transmitter output code A.
4. If ordering measurement type code M, DP Range 4 and 5 are not available.
5. DP Range 0 is only available with Measurement Type 3 or 4 and traditional flange, 316L SST diaphragm material, and Bolting option L4.
6. Required for Measurement Type codes 3 and 4.
7. For Measurement Type codes 1 and 2 with DP range 1, absolute limits are 0.5 to 2000 psi (0,03 to 137,9 bar) and gage limits are -14.2 to 2000 psig
(-0,98 to 137,9 bar).
8. Required for Measurement Type codes 2 and 4.
9. Required for Measurement Type codes 1 and 3. RTD Sensor must be ordered separately.
10. Materials of Construction comply with metallurgical requirements highlighted within NACE MR0175/ISO 15156 for sour oil field production environments
Environmental limits apply to certain materials. Consult latest standard for details. Selected materials also conform to NACE MR0103 for sour refining environments.
Order with Q15 or Q25 to receive a NACE certificate.
11. Tantalum diaphragm material is only available for DP Ranges 2–5.
12. “Assemble to” items are specified separately and require a completed model number.
13. Consult an Emerson representative for performance specifications.
14. Only available with Measurement Type 2 and multivariable type P.
15. Transmitter output code F is not available with Performance Class 1 and 2 and Measurement Type 3 and 4.
16. Only available with output code X.
17. Long-life power module must be shipped separately, order Power Module 701PBKKF.
18. For process connection option code A11, the mounting bracket must be ordered as part of the manifold model number.
19. Not available with transmitter output code F.
20. Not available with transmitter output code X.
21. Not available with process connection option code A11.
22. This assembly is included with certification options EP, KP, E1, N1, K1, ND, E4, E7, N7, K7, E2, E3, KA, KC, KD, EM, KM, IA, IE, IF, IG, KG.
23. Transmitter is shipped with 316 SST conduit plug (uninstalled) in place of standard carbon steel conduit plug.
24. FISCO is only available with transmitter output code F.
25. Not available with M20 or G
1
/2 conduit entry size.
26. RTD cable not available with this option.
27. Requires 316L SST diaphragm material, glass-filled PTFE O-ring (standard), and Process Connection code E12 or F12.
28. Bolts are not considered process wetted. In instances where NACE MR0175/ISO 15156 and NACE MR0103 conformance is required for bolting, L7 is the recommended
bolting option.
29. Not available with DP Range 0.
30. Only available with Measurement Type codes 3 and 4.
31. When assembled to remote diaphragm seal system using B11 or B12 process connections, the maximum working pressure of the system may be limited by the rating
of the Rosemount 1199 Seal System selected.
Table A-6. Rosemount 3051SMV HART
®
and Fieldbus Ordering Information
The starred offerings (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject to
additional delivery lead time.
