Emerson Dixell XR70T Installing And Operating Instructions

1592040000 XR70T EN v1.1 2019.07.09 XR70T 18/40
F2L
Number of working hours for relay output oA2 (units of)
F3H
Number of working hours for relay output oA3 (thousands of)
F3L
Number of working hours for relay output oA3 (units of)
F4H
Number of working hours for relay output oA4 (thousands of)
F4L
Number of working hours for relay output oA4 (units of)
5.1.12 Real Time Clock configuration parameters - rtC
Hur
Hours: 0 to 23 hours
Min
Minutes: 0 to 59 minutes
dAY
Day of the week: Sun to Sat
dYM
Day of the month: 1 to 31
Mon
Month: 1 to 12
YAr
Year: 00 to 99
Hd1
First day of weekend: (Sun to SAt; nu) setting for the first day of the weekend.
Hd2
Second day of weekend: (Sun to SAt; nu) setting for the second day of the weekend.
iLE
Energy saving cycle starting time on working days: (00h00min to 23h50min) during the
Energy Saving cycle, the set point is increased by the value in HES so that the operation set point
is SET+HES.
dLE
Energy saving cycle duration on working days: (00h00min to 24h00min) sets the duration of
the Energy Saving cycle on working days.
iSE
Energy saving cycle starting time on weekends: 00h00min to 23h50min
dSE
Energy saving cycle duration on weekends: 00h00min to 24h00min
ddx
Daily defrost enabled: (n; Y) to enable the Ld1 to Ld6 defrost operations for any day of the
week.
• dd1 = Sunday defrost
• dd2 = Monday defrost
• dd3 = Tuesday defrost
• dd4 = Wednesday defrost
• dd5 = Thursday defrost
• dd6 = Friday defrost
• dd7 = Sunday defrost
Ldx
Defrost starting time: (00h00min to 23h50min) these parameters set the beginning of the
programmable defrost cycles during any ddx day. Example: when Ld2=12.4, the second defrost
starts at 12:40 am during working days.
5.1.13 Memory storage management – E2
MAP
Current configuration: (C-1; C-2) to change configuration used.
LdM
Restore default factory settings: (n;Y) select Y and confirm to reload factory default values for
the configuration currently used.
rHA
Reset HACCP values: (n; Y) select Y and confirm to reset the memorized min and MAX
temperature values (HACCP function must be enabled).
5.1.14 Serial Communication port configuration parameters - CoM
Adr
Serial address: (1 to 247) device address for Modbus communication
bAU
Baudrate: (9.6; 19.2; 38.4; 57.6) select the correct baudrate for serial communication
PAr
Parity control: (no; odd; EvE) no=no parity control; odd=odd parity control; EvE=even parity
control
5.1.15 User Interface configuration parameters - Ui
SCS
User interface timeout: (1 to 255 sec) timeout before coming back to Home Screen or to
Programming Menu
bS
Sound Level: (0 to 5) select the sound level of the gestures
PSU
Password for protected level Pr2: (000 to 999) insert a value to protect all the parameters set
on the level Pr2 from modification
5.1.16 Information, read only parameters - inF
d1
Probe P1 value visualization
d2
Probe P2 value visualization
d3
Probe P3 value visualization
