d4
Probe P4 value visualization
rSE
Real regulation Set Point
FdY
Firmware release date: day
FMt
Firmware release date: month
FYr
Firmware release date: year
rEL
Firmware release: progressive number
Sub
Firmware sub release: progressive number
Ptb
Parameter map version
5.2 PARAMETER CONFIGURATION 1
Group
Par.
Description
Value
Protec
ted
U.O.M.
Range
rEG
SEt
Set Point
3.0
Pr1
°C
LS to US
rEG
LS
Minimum Set point
-100.0
Pr1
°C
[-100.0°C to SET]
[-148.0°F to SET]
rEG
US
Maximum Set point
150.0
Pr1
°C
[SET to 150.0°C]
[SET to 302.0°F]
rEG
HY
Compressor regulation differential in
normal mode
3.0
Pr1
°C
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
rEG
HYE
Compressor regulation differential in
energy saving mode
3.0
Pr1
°C
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
rEG
odS
Output activation delay at start-up
0
Pr1
min
0 to 255 min
rEG
AC
Anti-short cycle delay
0
Pr1
min
0 to 50 min
rEG
rtr
Regulation percentage=F(P1; P2)
(100=P1; 0=P2)
100
Pr2
0 to 100
rEG
CCt
Maximum duration for Pull Down
00:00
Pr2
hh:mm
0 to 23h50min
rEG
CCS
Pull Down phase differential (SET+CCS
or SET+HES+CCS)
0.0
Pr2
°C
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
rEG
oHt
Threshold for automatic activation of
Pull Down in normal mode
(SET+HY+oHt)
10.0
Pr2
°C
[0.0°C to 25.0°C]
[0.0°F to 45.0°F]
rEG
oHE
Threshold for automatic activation of
Pull Down in energy saving mode
(SET+HES+HYE+oHE)
10.0
Pr2
°C
[0.0°C to 25.0°C]
[0.0°F to 45.0°F]
rEG
Con
Compressor ON time with faulty probe
10
Pr1
min
0 to 255 min
rEG
CoF
Compressor OFF time with faulty probe
15
Pr1
min
0 to 255 min
Prb
ot
Probe P1 calibration
0.0
Pr1
°C
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
Prb
P2P
Probe P2 presence
Y
Pr1
n(0); Y(1)
Prb
oE
Probe P2 calibration
0.0
Pr1
°C
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
Prb
P3P
Probe P3 presence
no
Pr1
n(0); Y(1)
Prb
o3
Probe P3 calibration
0.0
Pr1
°C
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
Prb
P4P
Probe P4 presence
no
Pr1
n(0); Y(1)
Prb
o4
Probe P4 calibration
0.0
Pr1
°C
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
diS
CF
Temperature measurement unit:
Celsius; Fahrenheit
°C
Pr1
°C(0); °F(1)
diS
rES
Temperature resolution: decimal,
integer
dE
Pr1
dE(0); in(1)
diS
Lod
Probe default displayed
P1
Pr1
P1(0); P2(1); P3(2);
P4(3); SEt(4); dtr(5)
diS
rEd
Remote probe displayed (for XH-REP)
P2
Pr1
P1(0); P2(1); P3(2);
P4(3); SEt(4); dtr(5)
diS
dLy
Temperature display delay (resolution
10 sec)
00:00
Pr1
mm:ss
0.0 to 20min00sec
diS
dtr
Probe visualization
percentage=F(P1;P2) (ex: dtr=1
means VALUE=0.01*P1+0.99*P2)
99
Pr1
1 to 99
