Emerson Dixell XR70T Installing And Operating Instructions

1592040000 XR70T EN v1.1 2019.07.09 XR70T 36/40
18. TECHNICAL SPECIFICATIONS
FEATURES
DESCRIPTION
Housing
Self-extinguishing PC
Dimensions
Front fascia 38x80 mm; case depth 81mm
Mounting
Panel mounting, 71x29mm panel cut-out
Protection
Body: IP20; Front: IP66
Power Supply
230Vac 10%, 50/60Hz; 110Vac 10%, 50/60Hz; 100 to 240VAC10%, 50/60Hz; 12VAC 10%
Overvoltage category II
Rated Power
12VAC: 3VA; 110VAC: 4VA; 230VAC: 4VA; 100-240VAC: 3VA
Display
White display, LED type, 3 digits with decimal point and multi-function icons
Terminal blocks
Plug-in or screw terminal block, wire section between 0,5 and 2,5 mm2
Max tightening force: 0.3 N/m for 3,5mm pitch, 0.4 N/m for 5,0mm pitch
Environment
Pollution degree 2, non-condensing humidity
Operating Conditions
IEC: 0T60°C; 20-85 rH% (non-condensing humidity)
UL: -20T60°C; 20-85 rH% (non-condensing humidity)
Storage Conditions
-25T60°C; 20-85 rH% (non-condensing humidity)
Resistance to Heat and Fire
UL-V0
Measurement range
NTC: -40T110°C; resolution 0.1°C or 1°C (selectable)
PT1000: -100T150°C; resolution 0.1°C or 1°C (selectable)
PTC: -50T150°C; resolution 0.1°C or 1°C (selectable)
Accuracy
±1% compared to the full scale
Inputs
Up to 4 NTC, PTC or PT1000 (configurable)
Up to 2 voltage free contacts
Relay Outputs
Nominal
UL
IEC
oA1
SPST 16A,
250VAC
10FLA, 60LRA, 30k cycles
Pilot Duty B300, 6k cycles
10(4)A, 250 Vac, 50-60 Hz,
100K cycles
oA2
SPDT 8A,
250VAC
½ hp, 240 Vac, 30k cycles
Pilot Duty B300, 30k cycles
8(3)A, 230 Vac, 50-60 Hz,
50K cycles
oA3
SPST 8A,
250VAC
½ hp, 240 Vac, 30k cycles
Pilot Duty B300, 30k cycles
8(3)A, 230 Vac, 50-60 Hz,
50K cycles
oA4
SPST 5A,
250VAC
1.9FLA, 11.4LRA, 30k cycles
Pilot Duty B300, 30k cycles
5(1)A, 250 Vac, 50-60 Hz,
50K cycles
Action type 1B
Real Time Clock
Data maintenance up to 6 months with lithium battery
HOT KEY port
MAX voltage allowed is 5 VDC. DO NOT CONNECT ANY EXTERNAL POWER SUPPLY
Approvals
R290/R600a: relays tested according to IEC EN60079:0 and IEC EN60079:15
IEC60730-2-9: 2008 (Third Edition) and Am.1:2011 in conjunction with IEC 60730-1:2010 (Fourth
Edition)
UL 60730-1, 5th edition, dated August 03, 2016
UL 60730-2-9, 4th edition, dated February 14, 2017
CAN/CSA-E60730-1, 5th edition, dated November 01, 2017
CAN/CSA-E60730-2-9:15 3rd edition, dated September, 2015
