Emerson Micro Motion User Manual

5 Integrate with Rockwell
programming software
5.1 Integrate with Rockwell versions 20 or later
If you have Rockwell RSLogix 5000 or Studio 5000 Logix Designer version 20 or later
firmware and programming software, use this section to load the Electronic Data Sheet
(EDS) and commission the device using the RSLogix 5000 programming package.
Prerequisites
If you are upgrading the EDS from an older version, unregister the old EDS first using the
RSLogix EDS Hardware Installation Tool at Tools > EDS Hardware Installation Tool.
Procedure
1. Connect to the EtherNet/IP module through your web browser and download the
EDS file.
See Emerson web server.
2. In RSLogix 5000, choose
Tools
>
EDS Hardware Installation Tool
and register the
EtherNet/IP module EDS file.
3. If you have an established RSLogix Ethernet network, skip this step. If not, follow
these steps to create a network:
a) From RSLogix 5000, right-click the controller/backplane in the tree view.
b) Select
New Module
.
c) Select the appropriate Ethernet card.
d) Select
Create
.
e) Enter the
Name
.
f) Enter the
IP Address
.
g) Select the
Slot
where your Ethernet card is located.
h) Select
OK
.
i) On the
Select Module Type
window, select
Close
.
4. To add the Micro Motion EtherNet/IP module to the RSLogix 5000 Ethernet
network, right-click the Ethernet network and select
New Module
.
a) From the
Select Module Type
window, select the following options and
select
Create
:
Pane
Option
Module Type Category Filters Communications Adapter
Module Type Vendor Filters Micro Motion, Inc.
The New Module properties dialog displays. The EDS generates an Add On
Profile (AOP) for the Micro Motion Ethernet/IP module that loads all the
User Guide Integrate with Rockwell programming software
MMI-20019808 January 2019
User Guide 21
