Configuration Output parameters (explicit data)
Concentration measurement See Output parameters (explicit data) for concentration
measurement configuration
B.3 I/O data
B.3.1 Input assembly for standard configuration
Byte Access Name Type Notes
0–3 Get Mass flow rate Float
4–7 Get Density Float
8–11 Get Temperature Float
12–15 Get Volume flow rate (liquid
volume)
Float Valid only when Gas Standard Volume is not
enabled.
16–19 Get Mass total Float
20–23 Get Volume total (liquid
volume)
Float
24–27 Get Drive gain Float
28–29 Get Status word U16 or Word • For Model 1700 Analog, Model 2700 Analog,
Model 1500 Analog, Model 2500, and all Series
3000 transmitters: SNS Status Word 1 (see
Status Word 1)
• For MVD Direct Connect and 9739 MVD
transmitters: SNS Status Word 2 (see Status
Word 2)
30–31 Get Status word U16 or Word • For Model 1700 Analog, Model 2700 Analog,
Model 1500 Analog, Model 2500, and all Series
3000 transmitters: SNS Status Word 2 (see
Status Word 2)
• For MVD Direct Connect and 9739 MVD
transmitters: SNS Status Word 1 (see Status
Word 1)
32–35 Get Gas standard volume flow
rate
Float Valid only when Gas Standard Volume is enabled.
36–39 Get Gas standard volume total Float Valid only when Gas Standard Volume is enabled.
B.3.2 Output assembly for standard configuration
Byte Access Name Type Notes
0–3 Get/Set External Temperature Float
Device profile User Guide
January 2019 MMI-20019808
44 Micro Motion EtherNet/IP Module
