Chapter 4 Use Of Monitoring Module M500D 23
4.7.1 Parameter Setting Method
1. At any system information page, press “ENT” to enter the main menu.
Users with different password levels have different authorities. See the following table:
Table 1.1 Different password levels and relevant different authorities
Level Authority Default password
User Configuration of general parameters 1
Operator User’s authority, plus resetting system, resetting password and modifying system type 2
Administrator
Operator’s authority, plus modifying password of all levels, controling alarm sound
volume, browsing system parameters that can be set only through the host
640275
4. There are two pages of “Settings”. Shift page by using “▼” or “▲”, and select the parameter by using “▼” or “▲”.
Press “ENT” to confirm.
As shown in the above figure, the monitoring module divides the parameters to be set into 6 kinds: alarms parameter,
battery parameter, AC parameter, DC parameter, rectifier parameter and system parameter.
Among which, the battery parameters are divided into 5 kinds: basic, BLVD, charging management, battery test,
temperature coefficient, and they are displayed in two pages, as shown below:
What follows is the description of the parameter functions and values by dividing them into 5 small categories and 5
big categories.
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack Power Supply System User Manual
