3. The BC/FC switchover diagram is shown below:
Battery charge current
bigger than "To BC Current"
Battery capacity smaller
than "To BC Capacity"
Abnormal situation (such as AC failure,
FC
BC
Constant BC
time-up
Charge current
smaller than
"Constant BC
Curr"
Constant
BC
BC time longer than
"BC LVD Time"
FC time longer than "Scheduled BC Interval"
battery route faulty, and rectifier
communication failure etc.).
BC time longer than "Cyclic BC time"
Figure 1.1 BC/FC switchover diagram
4.7.5 Battery Test Parameters
1. There are seven related pages, as shown below:
BATTERY TEST
Voltage: 45.2 V
Time: 300 min
▼
Test End Cap:

0.700 C10
Planed Test:
N
▼
Planed Test1:
01.02 12Hr
Planed Test 2:
04.02 12Hr
Planed Test3:
07.02 12Hr
Planed Test4:
07.02 12Hr
SHORT TEST

Enable
:
Y
Alarm Current
:
10 A
▼
SHORT TEST
Cycle: 300h
Duration:
5 min
STABLE TEST
Enable
:
Y
Current
:
9999 A
▼
Use “▼” or “▲” to select one page or one of the parameters, and “◄” or “►” to select the parameter value. Press
“ENT” to confirm and save.
