24 Chapter 4 Use Of Monitoring Module M500D
4.7.2 Battery Selection
1. The first page of the Battery Selection is shown below:
Mode: Manual
Batt String: 2
Capacity: 300Ah
Batt Name: 1
＃ ▼
Use “▼” or “▲” to select the page and the parameter to be set, and “◄” or “►” to select the proper value for the
parameter. Press “ENT” to confirm.
After setting the “Battery Type”, the following prompt will appear, asking you to name a certain type of battery for the
sake of identifying them:
Battery Name:

Batt1
To name a rectifier, you can use “▲” or “▼” to change the number, and “◄” or “►” to move the cursor left or right.
Press “ENT” to confirm afterwards.
2. If setting parameter “System Type” does not require setting the battery shunt coefficient, the second page of the
basic battery settings is as follows:
Batt Shunt1:


Y
Batt Shunt2:
Y
3. If setting parameter “System Type” requires setting the battery shunt coefficient, the second page of the basic
battery settings is as follows:
Batt Shunt1: Yes

Batt Shunt2: Yes
Shunt coeff:
500A / 75mV
4. The value description of the basic battery parameters is listed below:
Table 1.1 Basic battery parameters descriptions
Parameter Range Defaults Value description
Mgmt Mode
(Management
mode)
Auto, Manual Auto
In normal situation, it should be in the “Auto” mode, which enables the
monitoring module manage the whole power system automatically,
including: Automatic FC/BC switchover, LLVD and BLVC. In the manual
mode, you can do operations like BC, FC, test and battery on/off, as well
as enabling automatic battery BC time protection and capacity
calculation. Upon the system DC under-voltage alarm, system can
automatically switch to the “Auto” mode, lest wrong manual operation
should damage the system
Batt String (number
of battery strings)
0 ~ 4 2
You should set this parameter according to the actual battery
configuration. If “Batt Shunt” is set as “Y”, there should be batteries
actually configured
Rated AH (rated
capacity)
50 ~ 5000Ah 300Ah
The total capacity of the battery strings connected to one battery shunt.
You should set this parameter according to the actual battery
configuration
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack Power Supply System User Manual
