A Specifications and Reference Data
A.1 Functional specifications
A.1.1 Input power
10.5–30 VDC (must be a Class 2 power supply)
A.1.2 Power over Ethernet
Note
The current consumption is for Gateway operation only. If using PSE, calculations will need
to be made to include the device being powered.
Input voltage
Normal Operation (no PSE or IEEE 802.3af): 10.5–30 VDC
PoE + PSE Operation (IEEE 802.3at): 17.5–30 VDC
A.1.3
Current draw
Operating current draw is based on 3.6 Watts power consumption.
A. Current (mA)
B. Voltage (VDC)
Momentary startup current draw up to twice operating current draw.
A.1.4
Radio frequency power output from antenna
Maximum of 10 mW (10 dBm) EIRP
Reference Manual Specifications and Reference Data
00809-0200-4420 September 2020
Emerson.com/Rosemount 65
