Setting Up the Projector 35
4. You may also be able to use the remote control as a wireless mouse
(see page 61).
When you’ve finished making connections, see page 45 for
instructions on turning on the projector and Chapter 2 for
instructions on displaying and adjusting the image.
Connecting to Video Equipment
You can connect several video sources to the projector at the same
time. Before starting, look at your video equipment to determine its
available video output connections:
■ EX5200/EX7200 only: If your video device has an HDMI
connector, see “Connecting an HDMI Video Source (EX5200/
EX7200 Only)” on page 36.
■ If your video device has a yellow RCA video output connector, see
“Connecting a Composite Video Source” on page 37.
■ If your video device has an S-Video connector, see “Connecting
an S-Video Source” on page 38.
■ If your video device has a component video port (three connectors
labeled either Y/Cb/Cr or Y/Pb/Pr), see “Connecting a
Component Video Source” on page 39.
■ If your video device has an RGB video port, see “Connecting an
RGB Video Source” on page 40.
After connecting video cables, you may also want to connect an
optional audio cable to play sound through the projector; see page 41.
If you connect using an HDMI cable (EX5200/EX7200 only), the
video and sound are both transferred and you won’t need to connect
any additional cables for audio.

Epson EX3200 Specifications

Projection Specifications

pixel number	480, 000 dots (800 x 600) x 3
white light output	2600 lumens
color light output	2600 lumens
aspect ratio	4:3
native resolution	800 x 600 (SVGA)
contrast ratio	Up to 2000:1
color reproduction	16.77 million colors
lamp type	200 W UHE
lamp life in ECO Mode	Up to 5000 hours
lamp life in Normal Mode	Up to 4000 hours
throw ratio range	1.45 – 1.96
size projected distance	30" – 350" (0.76 – 8.90 m)
keystone correction vertical	± 30 degrees

Lens Specifications

f-number	1.44
focal length	16.6 mm
zoom ratio	Digital zoom 1.0 – 1.3

Power and Noise

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	280 W
power consumption power off	0.3 W
fan noise normal mode	37 dB
fan noise ECO mode	29 dB

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
operating angle right/left	± 30 degrees
operating angle upper/lower	± 15 degrees
operating distance	19' (6 m)

Dimensions and Weight

dimensions including feet	11.6" x 9.0" x 3.1"
dimensions excluding feet	11.6" x 9.0" x 3.0"
weight	5.1 lb/2.3 kg
