Epson EX3200 User Manual

5
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using Your Documentation . . . . . . . . . . . . . . . . . . . . . . . . . 10
Getting More Information . . . . . . . . . . . . . . . . . . . . . . . 10
Projector Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Projector Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . 14
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Projector Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Registration and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Optional Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1
Setting Up the Projector . . . . . . . . . . . . . . . . . . . . . 21
Unpacking the Projector. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Additional Components. . . . . . . . . . . . . . . . . . . . . . . . . 23
Positioning the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Projector Placement Options . . . . . . . . . . . . . . . . . . . . . 30
Connecting to a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . 31
Connecting to the USB Port . . . . . . . . . . . . . . . . . . . . . 31
Installing Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Connecting to the VGA Computer Port . . . . . . . . . . . . 34
Connecting to Video Equipment . . . . . . . . . . . . . . . . . . . . . 35
Connecting an HDMI Video Source
(EX5200/EX7200 Only) . . . . . . . . . . . . . . . . . . . 36
Connecting a Composite Video Source . . . . . . . . . . . . . 37
Connecting an S-Video Source . . . . . . . . . . . . . . . . . . . 38
Connecting a Component Video Source . . . . . . . . . . . . 39
Connecting an RGB Video Source. . . . . . . . . . . . . . . . . 40
Playing Sound Through the Projector. . . . . . . . . . . . . . . . . . 41
Connecting External Speakers
(VS200/EX3200 Only) . . . . . . . . . . . . . . . . . . . . 42

Epson EX3200 Specifications

Projection Specifications

pixel number	480, 000 dots (800 x 600) x 3
white light output	2600 lumens
color light output	2600 lumens
aspect ratio	4:3
native resolution	800 x 600 (SVGA)
contrast ratio	Up to 2000:1
color reproduction	16.77 million colors
lamp type	200 W UHE
lamp life in ECO Mode	Up to 5000 hours
lamp life in Normal Mode	Up to 4000 hours
throw ratio range	1.45 – 1.96
size projected distance	30" – 350" (0.76 – 8.90 m)
keystone correction vertical	± 30 degrees

Lens Specifications

f-number	1.44
focal length	16.6 mm
zoom ratio	Digital zoom 1.0 – 1.3

Power and Noise

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	280 W
power consumption power off	0.3 W
fan noise normal mode	37 dB
fan noise ECO mode	29 dB

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
operating angle right/left	± 30 degrees
operating angle upper/lower	± 15 degrees
operating distance	19' (6 m)

Dimensions and Weight

dimensions including feet	11.6" x 9.0" x 3.1"
dimensions excluding feet	11.6" x 9.0" x 3.0"
weight	5.1 lb/2.3 kg
