78 Fine-Tuning the Projector
2. Select the type(s) of password protection you want to use:
Power On Protect: Prevents unauthorized use of the
projector. After the projector is plugged in and turned on,
you must enter a password to use the projector. Select
On,
press
Enter, then press Esc to return to the Password Protect
screen.
User’s Logo Protect: Prevents your custom screen (see
page 79), display, and User’s Logo settings in the Extended
menu from being changed. Select
On, press Enter, then press
Esc to return to the Password Protect screen.
3. Use the arrow buttons to select
Password and press Enter.
4. When you see a message asking if you want to change the
password, select
Yes and press Enter.
5. Hold down the
Num button and use the numeric keypad to enter
a four digit password.
6. When you see a confirmation message, reenter the password.
7. Press the
Menu button, then press Enter to exit the screen.
8. Turn off and unplug the projector.
Starting the Projector With a Password
When the password function is enabled, you see this screen when you
plug in and turn on the projector:
Hold down the
Num button and use the numeric keypad to enter the
four digit password.
The password screen closes and projection begins.
Hold down
note
If you leave the projector
p
lugged in, the Password
screen will not appear. It
appears only if you unplug
and reconnect the power
cord.
Hold down

Table of Contents

Other manuals for Epson EX3200

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EX3200 and is the answer not in the manual?

Epson EX3200 Specifications

Projection Specifications IconProjection Specifications
pixel number480, 000 dots (800 x 600) x 3
white light output2600 lumens
color light output2600 lumens
aspect ratio4:3
native resolution800 x 600 (SVGA)
contrast ratioUp to 2000:1
color reproduction16.77 million colors
lamp type200 W UHE
lamp life in ECO ModeUp to 5000 hours
lamp life in Normal ModeUp to 4000 hours
throw ratio range1.45 – 1.96
size projected distance30" – 350" (0.76 – 8.90 m)
keystone correction vertical± 30 degrees
Lens Specifications IconLens Specifications
f-number1.44
focal length16.6 mm
zoom ratioDigital zoom 1.0 – 1.3
Power and Noise IconPower and Noise
power supply voltage100 – 240 V ±10%, 50/60 Hz
power consumption280 W
power consumption power off0.3 W
fan noise normal mode37 dB
fan noise ECO mode29 dB
Operating Environment IconOperating Environment
operating temperature41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
operating angle right/left± 30 degrees
operating angle upper/lower± 15 degrees
operating distance19' (6 m)
Dimensions and Weight IconDimensions and Weight
dimensions including feet11.6" x 9.0" x 3.1"
dimensions excluding feet11.6" x 9.0" x 3.0"
weight5.1 lb/2.3 kg
