Roll Paper Holder
The optional roll paper holder (C811141) allows you to use 8.5-inch roll paper like that used with telex
machines. This provides an inexpensive alternative to using continuous paper for applications
requiring variable paper lengths. Before you install and use the roll paper holder, you need to assemble
it.
Assembling the roll paper holder
Follow these steps to assemble the roll paper holder:
1. Fit the arc bearings into the stand as shown.
2. Place the base plate on the stand and fasten the two together with the plastic spacing clips. Make
sure you orient the stand and base plate as shown below.
3. Hook the tension lever onto both ends of the stand as shown below. While pulling up on the
tension lever, fit the wire ends of the tension lever into the holes in the stand. The roll paper holder
is assembled.
LQ-590II/LQ-590IIN/LQ-2090II/LQ-2090IIN User’s Guide
Options and Consumables 137

Epson LQ-590II Specifications

General

Mean time between failures (MTBF)	25000 h
Color	-
Character sets	ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8
Built-in barcodes	Code 39, EAN13, EAN8, Interleaved 2/5, POSTNET, UPC-A, UPC-E
Maximum printing width (columns)	80
Standard interfaces	Ethernet, USB 2.0
Continuous paper thickness range	0.065 - 0.49 mm
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Pallet width	800 mm
Pallet height	7430 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	28 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)
Package depth	340 mm
Package width	40 mm
Package height	80 mm
Package weight	9280 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	437 mm
Height	177 mm
Weight	7200 g
