Epson LQ-590II User Manual

Chapter 1
Paper Handling
Selecting a Paper Source
Your printer provides a variety of paper sources for printing on single sheets and continuous paper.
Paper can be fed into the printer from the front, bottom, or rear. Select the paper source that best suits
your current printing needs.
!
Caution:
Do not use paper that is folded, creased, curled, torn, stained, or stamped. Always use new, clean
paper that meets the paper specifications. See “Paper” on page 150 for more details.
Printing on continuous paper
You can choose from three tractor positions (front push, rear push, and pull) and three paper entry
slots (front, rear, and bottom) for continuous paper printing. This section helps you determine which
paper paths and tractor positions are best for your continuous paper printing needs. See “Loading
continuous paper with the tractor” on page 21 for tractor installation and paper loading
instructions.
Using the push tractor positions
If you often need to tear off sheets of continuous paper (for example, if you are printing purchase
orders or sales slips), it is best to use the tractor in the front or rear push position. This allows you to use
the printer’s tear-off edge to easily tear off sheets of continuous paper at the perforation. Also, when
continuous paper is loaded on a rear push tractor, you can print on single sheets of paper from the
sheet guide without removing the continuous paper from the tractor.
There are two push tractor positions: front and rear. See the table below for details about the push
positions and the corresponding paper paths.
LQ-590II/LQ-590IIN/LQ-2090II/LQ-2090IIN User’s Guide
Paper Handling 16

Epson LQ-590II Specifications

General

Mean time between failures (MTBF)	25000 h
Color	-
Character sets	ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8
Built-in barcodes	Code 39, EAN13, EAN8, Interleaved 2/5, POSTNET, UPC-A, UPC-E
Maximum printing width (columns)	80
Standard interfaces	Ethernet, USB 2.0
Continuous paper thickness range	0.065 - 0.49 mm
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Pallet width	800 mm
Pallet height	7430 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	28 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	4 pc(s)
Package depth	340 mm
Package width	40 mm
Package height	80 mm
Package weight	9280 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	437 mm
Height	177 mm
Weight	7200 g
