A
Printer cover Open when replacing ink cartridges or removing jammed paper
inside the printer.
B
Paper cassette 1 Loads paper.
C
Paper cassette 2
D
Ink cartridge cover Open when replacing ink cartridges.
E
Ink cartridge holder Install the ink cartridges. Ink is ejected from the print head nozzles
underneath.
A
Rear cover 2 Remove when removing jammed paper.
B
Rear cover 1 Open when replacing the maintenance box or removing jammed
paper.
C
AC inlet Connects the power cord.
D
LAN port Connects a LAN cable.
E
USB port Connects a USB cable.
Control Panel
A
Pass a smart device over this mark to print from the smart device directly.
User's Guide
Printer Basics
14
