ESAB Cutmaster 60 User Manual

ESAB CUTMASTER 60
Manual 0-5402 INTRODUCTION
2-3
2.05 Input Wiring Specifications
ESAB Cutmaster
®
60 Power Supply Input Cable Wiring Requirements
Input voltage Freq Power Input Suggested Sizes
Volts Hz kVA I
1max
I
1eff
Fuse (amps)
Flexible Cord (Min.
AWG)
3 phase
380 50/60 11 16 11 20 14# (around
2.5mm
2
)
400 50/60 11 16 11 20 14# (around 2.5mm
2
)
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on US Electric Code and Canadian Electric Code
NOTE!
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
I
1max
is taken at rated minimum duty cycle.
I
1e
is taken at 100% rated duty cycle.

ESAB Cutmaster 60 Specifications

General

Brand	ESAB
Model	Cutmaster 60
Category	Welding System
Language	English
